GENERAL
MODEL NO.
PH-GO360D30_DWT01
MATERIALS
Aluminum | ABS Plastic | Copper
COLOR
Black
INTEL COMPATIBILITY
LGA 115x | 1200 | 1700 | 2011 | 2011-3 | 2066
AMD COMPATIBILITY
AM4 | AM5
RADIATOR DIMENSIONS
Length x Width x Height
397 x 120 x 27 mm | 15.62 x 4.72 x 1.06 in
PUMP DIMENSIONS
Length x Width x Height
76 x 64 x 51.4 mm | 2.99 x 2.51 x 2.02 in
PUMP DETAILS
TUBE DETAILS
MOTOR SPEED
3100 RPM ± 10% (100% Duty Cycle)
POWER
12V | 0.38A – 0.45A | 4.56W – 5.4W
PUMP DC CABLE
490 mm
SOUND LEVEL
20.0 dBA
MATERIAL
Copper | ABS
D-RGB CONNECTOR
3-Pin D-RGB Daisy-chain
D-RGB CABLE LENGTH
500 + 90 mm
LENGTH
400 mm | 15.74 in
DIAMETER
10.5 mm OD | 0.41 in OD
TUBE CLIPS
3x
MATERIAL
CIIR rubber | Braided sleeves
FANS 3X INCLUDED
FAN MODEL
D30-120 D-RGB PWM
DIMENSIONS
Length x Width x Height
120 x 120 x 30 mm | 4.72 x 4.72 x 1.18 in
SPEED
250 – 2000 ± 10% RPM
AIR FLOW
64.3 CFM
FAN STATIC PRESSURE
3.01 mm H2O | 0.11 in H2O
SOUND LEVEL
30.2 dBA
MTFB
150.000 Hours
PWM CONNECTOR
4-Pin Daisy-chain
PWM CABLE LENGTH
700 mm | 27.55 in
D-RGB CONNECTOR
3-Pin D-RGB Daisy-chain
D-RGB CABLE LENGTH
600 + 100 mm | 23.62 + 3.93 in
EXTRA
NET WEIGHT
1.91 kg | 4.21 lbs
GROSS WEIGHT
2.99 kg | 6.59 lbs
SCOPE OF DELIVERY
1x Glacier One 360D30 AIO cooler
3x D30-120 fans
ACCESSORY BOX
3x Tube clip
1x SATA to 2-pin pump adapter
1x D-RGB Mainboard adapter 600 mm
1x PH-NDC Thermal paste
1x Installation guide
MOUNTING HARDWARE
4x AM4 | AM5 Stand-Off screws
4x LGA 1700 Stand-Off screws
4x LGA 115X | 1200 Stand-Off screws
4x LGA 2011 | 2066 Stand-Off screws
4x Thumb nuts
1x AM4 | AM5 Bracket
1x LGA 115X | 1200 | 1700 | 2011 | 2066 Bracket
1x LGA 115X | 1200 | 1700 Metal back plate
SCREWS
12x 33 mm 6-32 UNC radiator screws
12x 35 mm 6-32 UNC radiator screws
12x 6 mm 6-32 UNC radiator screws
D30 FAN COMPONENTS
1x Corner clip connector
3x Corner clip
2x Bridge clip connector
2x Bridge clip
4x Screw cover bridge
2x Screw cover L
2x Screw cover R
